HOME > Product Profile
DB connector
pdf Catalog pdf Manual Shopping Site
Product Profile
SeriesDB connector
CategoryInsulation Displacement Connectors (Wire-to-Board Board-in type)
TypeIDC style, Board-in connector
Board-in connector
Specification
Pitch2.5mm
Current rating2A (AWG#24)
Voltage rating250V
PC board mounting directionTop entry
Product description
*Twin U-slot ID section
*Locking solder tail
*The DB connector has the same board layout and hose size as crimp style SCN connector.

DB connector
